UV-A tester for Analysing UV-A lamps with your mobile
The new Bluetooth UV-A tester has been developed to check status of UV-A lamps out in the field. It can be used by service technician, sales persons, but also by clients and auditor inspectors.This tool was designed to offer a price competitive, easy to use tool, which will allow you to check status on the efficiency of UV-A lamps. As we all know: there is still little or no awareness on the fact that UV-A light diminishes over time and as a result lamps are not replaced or replaced too late.
This is a compact and easy to use UV sensor, used to measure UV-A output from UV lamps, which will replace the previous model
How to use the bluetooth UV-A tester?
The bluetooth UV tester measures and analyses the UV-A light from your UV-A lamps inside your flytrap/insect-trap. It connects to every Smartphone via Bluetooth 4.0 or higher..
This enables you to ensure your insect-traps are working efficiently. You can also compare and see for yourself how much more efficient the ASTRON or SIGNIFY/PHILIPS UV-A lamps are!
In fact, unless you are using ASTRON or PHILIPS bulbs already, you might be surprised at how little UV-A light is coming off many other lamps!
The Alcochem UV-A tester simply works with your smartphone
Connect the bluetooth UV-A tester to your Smartphone with the Alcochem app (available in the app stores). The UV-A tester is powered by a cell battery with a lifespan approx. 1 year.
To provide the data you need to ensure your lamps are working to keep your premises free of flying insects.
Model
Suitable for
Interface
UV-A measuring range
Accuracy
Battery
Size
Weight (incl. bumper)
Supported smartphones
Supported Bluetooth
Material bumper
Approval
Protection level
Storage temperature
Guarantee
UV-A lamp tester BT
Measuring UV-A lamps (lamp types as shown in the App)
Bluetooth 4.2 BLE (Bluetooth Low Energy)
310-400 nm
+/- 80%
CR2032 Button cell
40 x 80 x 17 mm
38 gram
Android 4.2 or higher, iOS 8.0 or higher
4.0 or higher
Silicone
CE approved
IP20
5-60 ◦C
1 year return to base on electrical failures
The new Bluetooth UV-A tester has been developed to check status of UV-A lamps out in the field. It can be used by service technician, sales persons, but also by clients and auditor inspectors.
The Solution
The Smartphone as the process and read-out tool. For the connection between the Bluetooth UV sensor and the Smartphone we use the Bluetooth communication, which is simple to use and reliable.
A special app is developed, which can be freely downloaded for the iPhone and the Android based smart phones from May / June 2021 onwards. Simply go to the Google play store or the App store and download the Bluetooth UV-A tester software (free of advertising)
Simply search for: Bluetooth UV-A tester
The software offers
- A read out in a visual display, an absolute value and an indicative signal.
- The possibility to store the photo with the read-out value
- The possibility to email the photo with the read-out value
- A link to the website, were more details are available
- A FAQ section
Install the app on Smartphone
- Download the App on your smart phone
- Make sure the Bluetooth function on your phone is working
- Open up the App, it now opens the screen: Find devices
- Switch on the Bluetooth UV tester ( blue LED shows that is in operation)
- On the App press the round search button
- In the search field an item is shown. By pressing the SELECT button you can now make a blue tooth connection. Once you have done this, the measurement screen opens up and you can take a UV measurement
